Air Mouse 2.4G Remote Control

Cursor Keys

Switch on and off.

Mute

Switch to mute and unmute.

Circle Touch VOL +/-

Adjust volume up and down.

CH +/-

Selects channels up or down.

Power

Move through menus or guides.

Select Key

Select or deselect screen item.

Left Key

Move to the left item on screen.

Right Key

Move to the right item on screen.

Item ID: DSR-0376

Special Features

Air Fly Mouse: 4 Axis gyration motion system allows remote to be controlled accurately for motion sensing game, it’s more convenient to operate in a horizontal and vertical mode for games and typing.

Innovative Shape: Keyless, portable, elegant, simple but high-end appearance.

Remote Locator: Simply push a button on the devices and the remote will beep and blink to help you find it.

Auto Sleep And Wake Up: When the remote control for 15 seconds without any operation, the remote control into sleep mode, blue light is off(Save Power). After the remote control entering hibernation, press any key to wake up the remote control to enter the normal working condition.

General Features

Protocol: 2.4G

Keys: 14

Keypad Type: ABS plastic

Power Supply: 2*AAA

Operating Voltage: 2.0~3.6V

Working frequency: 2.40GHz~2.48GHz

Transmission distance: 20~30ft(airmouse) 30~50ft(Key)

Standby current: ≤50uA

Optical power:Intermediate ≥60 UW / cm², on both sides of 15 °≥20 UW / cm² (distance 50cm)





Applications

LED/LCD TV .HD-Set Top Box

Audio / Video Equipment
Home automation applications
Computer control
